VEX-E4701TR

ST-400

9-Button Control Keypad

UK 2-gang or 1-gang wall plate design , Adjustable LED button brightness , 60 (36 on the 1-gang) macros for controlling user equipment , Up to 128 total commands can be stored and used across all macros in the system (up to 16 per macro), Supports switchable relays to control compatible devices , Supports time and date macro scheduling (single and recurring) , Supports condition checking within macro commands for expanded macro design flexibility , Supports one month of backup power for the internal clock and schedule function to protect against blackouts and temporary power loss , Supports customizable daylight savings time configuration , Can be powered by an Ethernet switch that supports the IEEE 802.3af PoE standard (Optional) , Controllable via keypad, Telnet and WebGUI

CH-U331HTXWPUK

Video, audio and control transmission over TCP/IP in Unicast (point-to-point) or Multicast (single-to-many, many-to-many) modes, When connected, the analog Line In audio is automatically embedded into the transmitted signal for output on connected Receivers via HDMI and their analog Line Out ports, The Mic In on a connected Receiver will send audio directly to the analog Line Out on this Transmitter, May be powered directly by PoE when connected to a Gigabit Ethernet switch that provides PoE (802.3af), Supports USB keyboard, mouse and storage extension

SPH-130

CPLUS-1082VA

Routes ten HDMI sources to ten displays using eight HDBaseT outputs and two independent or mirrored HDMI outputs, Supports Deep Color input and output up to 12-bit , Supports 10-bit and 12-bit HDR bypass, Supported HDBaseT feature set: HD Video & Audio, 100BaseT Ethernet, 48V PoH, and Control (Bidirectional IR/RS-232 pass through), All HDBaseT outputs support OAR (Optical Audio Return), 4K signals can be transmitted up to 70m via Cat.5e/6 and up to 100m via Cat.6a/7, Supports pass-through of these standard digital audio formats via HDMI/HDBaseT: LPCM 2.0/5.1/7.1, Bitstream, and HD Bitstream, Advanced DAC (Digital to Analog Conversion) and ADC (Analog to Digital Conversion) for audio integration, Supports integrated audio over CAT inputs and outputs for transmission up to 300m, Supports volume, treble, bass, and audio delay for lip-sync (up to 230ms) on analog audio outputs and mute on all outputs, Audio mixer functionality (three mixers in total), Advanced internal and external EDID management with 4 sets of configurable EDID settings, Internal test pattern generation (up to 1080p) for self and sink testing, 2U rack mounted design, Control via front panel buttons with OLED menu, Ethernet (Telnet & WebGUI), RS-232, and IR remote

CH-1602TX

Supports the HDBaseT 2.0 specification over a single Cat.6/7 cable up to, 100m/328ft and Cat.5e cable up to 90m/295ft, HDBaseT 5Play™ convergence: High-Definition (HD) Video and Audio, 100BaseT Ethernet, 48V PoH, and Control (Bi-directional IR/ RS-232 pass-through), Receiver (PD) is powered by 48V PoH from the transmitter (PSE), HDMI with 3D & 4K@60Hz (YUV 4:2:0) support, 1×USB 2.0 Mini-B port (on the transmitter), 2×USB 2.0 Type A ports (on the receiver), Supports pass-through of HD audio formats: LPCM 2.0/5.1/7.1, Bitstream, and HD Bitstream, Supports optical audio sampling rates up to 48kHz, Supports external analog and digital audio extension including support for ARC (Audio Return Channel), Supports RS-232 baud up to 115200bps, Ultra-thin mechanical design

VEX-E4501R

HDMI input and output with 3D & 4K video support (18Gbps), 1 HDMI output (Functions as local monitor output), HDBaseT 3.0 compatible, Backward compatibility with HDBaseT 2.0/1.0 product, Supports HDBaseT features: HD video and audio, individual 1000BaseT and 100BaseT Ethernet ports, POH and control (bi-directional IR/RS-232/ USB pass-through), Supports analog audio and optical audio pass-through., Multiple USB hosts may be connected at once (up to 2 total, between the Tx and a compatible Rx unit) with a single selected host active at a time, Supports providing PoH power from Transmitter to Receiver in same HDBaseT port.

SPH-170C
