UHD+ HDMI to Dual HDMI Scaler with Audio De-Embedding & Test Patterns

Klicken zum Vergrößern

Cypress Technology

UHD+ HDMI to Dual HDMI Scaler with Audio De-Embedding & Test Patterns

HDMI signal bypass on both outputs or upscales 1080p signals to 4K on output B and downscales 4K signals to 1080p on output A , 4K UHD (4:4:4) to 4K UHD (4:2:0) conversion , Integrated EDID management , Test pattern generation at selected resolutions for on-site display testing , Supports High-Dynamic-Range (HDR) sources , Supports data rates up to 18Gbps (600MHz) and Deep Color up to 1080p/16-bit , Supports pass-through of HD audio formats including LPCM2.0/5.1/7.1, Bitstream, and HD Bitstream , OSD with instant I/O resolution display , Supports the Apple source compatibility mode option

Hersteller-Nr.	CPLUS-V2PE
Hersteller	Cypress Technology

This HDMI to Dual HDMI Scaler with Audio De-Embedding & Test Patterns is designed to upscale 1080p signals into 4K UHD (18Gbps) or downscale 4K UHD (18Gbps) signals into 1080p with synchronized digital and analog audio output. A friendly and simple interface design allows the user to control the unit while viewing the OSD directly on the HDMI output. The input signal can be output to both HDMI outputs simultaneously with a different resolution on each or the unit can generate a test pattern at a preferred video resolution for easy on-site display testing and validation. This UHD Scaler is the best tool to use with your HD and UHD signals.

Interfaces
Input Port	1 HDMI
Output Port	2 HDMI 2 RCA (Stereo Audio)

Video
HDMI Compliance	HDMI 2.0 (DVI 1.0)
HDCP Compliance	2.3
Input Signal Types	4K@60 8bit 4:4:4
Output Signal Type	4K@60 8bit 4:4:4

Resolutions
Maximum Input	HDMI	4096×2160p@60
Maximum Output	HDMI	4096×2160p@60

Power
Power Supply	5V/2.6A DC (US/EU standards, CE/FCC/UL certified)
Power Consumption	5.8W

Enclosure
Chassis Material	Metal
Chassis Color	Black
Dimensions (W×H×D)	231.5mm×25mm×108mm [Case Only] 231.5mm×25mm×117mm [All Inclusive]
Weight	616g

Field Firmware Update
Interface	USB

Ordering Information
Model No.	Product Description
CPLUS-V2PE	UHD+ HDMI to Dual HDMI Scaler with Audio De-Embedding & Test Patterns

Keine Maßangaben verfügbar.

Verkaufspreis (Netto)

Auf Anfrage

zzgl. 10,00 € Versand • ab 500 € versandkostenfrei

Auf Bestellung

Lieferzeit: ca. 30 Tage
