GIGA BRIX GB-BRi3H-10110 Barebone (Intel Core i3-10110U 2C/4T)
| EAN/GTIN | 4719331191474 |
| Hersteller-Nr. | GB-BRI3H-10110 |
| Hersteller | Gigabyte |
| Prozessor | |
| Anzahl Prozessorkerne | 2 |
| Prozessor-Taktfrequenz | 2.1 GHz |
| Prozessorhersteller | Intel |
| Prozessor Lithografie | 14 nm |
| Prozessorfamilie | Intel® Core™ i3 Prozessoren der 10. Generation |
| Prozessor | i3-10110U |
| Prozessor-Threads | 4 |
| Eingebauter Prozessor | Ja |
| Prozessor Boost-Frequenz | 4.1 GHz |
| Netzwerk | |
| Ethernet (LAN) | Ja |
| Bluetooth | 4.2 Ja |
| LAN-Controller | Realtek RTL8111HS |
| WLAN | Ja |
| WLAN-Standards | Wi-Fi 5 (802.11ac) |
| Design | |
| Kensington Lock | Ja |
| Produkttyp | Mini-PC Barebone |
| Slot-Typ Kabelsperre | Kensington |
| VESA-Halterung | Ja |
| Produktfarbe | Schwarz |
| VESA-Montage-Schnittstelle | 75 x 75.100 x 100 mm |
| Speichermedium | |
| Speichermedien Typ | Festplatte, SSD |
| SSD-Formfaktor | 2.5" |
| Speichermedien Schnittstelle | M.2, PCI Express, SATA |
| Anzahl Einschübe | 1 |
| unterstützte Speicherlaufwerksgrößen | 2.5 Zoll |
| Technische Details | |
| Hersteller | Gigabyte |
| Anschlüsse und Schnittstellen | |
| USB 3.2 Gen 2 (3.1 Gen 2) Anzahl der Anschlüsse vom Typ A | 5 |
| USB 3.2 Gen 2 (3.1 Gen 2) Anzahl der Anschlüsse vom Typ C | 1 |
| Anzahl LAN-Anschlüsse (RJ-45) | 1 |
| Gleichstrom-Anschluss (DC) | Ja |
| Anzahl COM-Anschlüsse | 1 |
| Anzahl HDMI-Anschlüsse | 2 |
| Kombinierter Kopfhörer (Mikrofon-Anschluss) | Ja |
| Erweiterungssteckplätze | |
| Anzahl der M.2 (M)-Steckplätze | 1 |
| PCI-Slots | 1 |
| Gewicht und Abmessungen | |
| Höhe | 46.8 mm |
| Breite | 119.5 mm |
| Tiefe | 119.5 mm |
| Grafik | |
| Maximale Auflösung | 4096 x 2304 Pixel |
| Grafikkarte | UHD Graphics |
| Grafikkarte-Familie | Intel |
| Eingebaute Grafikadapter | Ja |
| Leistungen | |
| Audio-Chip | Realtek ALC255 |
| Unterstützt Windows-Betriebssysteme | Windows 10 |
| Energie | |
| Stromversorgung | 90 W |
| Netzteil Ausgangsspannung | 19 V |
| AC-Adapter Ausgangssstrom | 4.3 A |
| Betriebsbedingungen | |
| Betriebstemperatur | 0 - 50 °C |
| Temperaturbereich bei Lagerung | -20 - 60 °C |
| Speicher | |
| Arbeitsspeicher Typ | SO-DIMM |
| RAM-Speicher maximal | 64 GB |
| Anzahl der Speichersteckplätze | 2 |
| Unterstützte Arbeitsspeichergeschwindigkeit | 2666 MHz |
Prozessor
| Prozessorhersteller | Intel |
| Prozessorfamilie | Intel® Core™ i3 |
| Prozessorgeneration | Intel® Core™ i3 Prozessoren der 10. Generation |
| Prozessor | i3-10110U |
| Anzahl Prozessorkerne | 2 |
| Prozessor-Threads | 4 |
| Prozessor Boost-Frequenz | 4,1 GHz |
| Prozessor-Taktfrequenz | 2,1 GHz |
| Eingebauter Prozessor | Ja |
| Prozessor Lithografie | 14 nm |
| Thermal Design Power (TDP) | 15 W |
| Prozessor Codename | Comet Lake |
| CPU Konfiguration (max) | 1 |
Speicher
| Arbeitsspeicher Typ | SO-DIMM |
| Anzahl der Speichersteckplätze | 2 |
| RAM-Speicher maximal | 64 GB |
| Unterstützte Arbeitsspeichergeschwindigkeit | 2666 MHz |
Speichermedium
| Unterstützte Speicherlaufwerke | HDD & SSD |
| unterstützte Speicherlaufwerksgrößen | 2.5" |
| SSD-Formfaktor | 2.5" |
| Speicherlaufwerk Schnittstelle | M.2, PCI Express, SATA |
| Anzahl der unterstützten Speicherlaufwerke | 1 |
Grafik
| Eingebaute Grafikadapter | Ja |
| Grafikkarte-Familie | Intel |
| Eingebautes Grafikkartenmodell | Intel® UHD Graphics |
| Maximale Auflösung | 4096 x 2304 Pixel |
Netzwerk
| WLAN-Standards | Wi-Fi 5 (802.11ac) |
| Ethernet/LAN | Ja |
| WLAN | Ja |
| LAN-Controller | Realtek RTL8111HS |
| Bluetooth | Ja |
| Bluetooth-Version | 4.2 |
Anschlüsse und Schnittstellen
| USB 3.2 Gen 2 (3.1 Gen 2) Anzahl der Anschlüsse vom Typ A | 5 |
| USB 3.2 Gen 2 (3.1 Gen 2) Anzahl der Anschlüsse vom Typ C | 1 |
| Anzahl HDMI-Anschlüsse | 2 |
| Kombinierter Kopfhörer-/Mikrofon-Anschluss | Ja |
| Anzahl Ethernet-LAN-Anschlüsse (RJ-45) | 1 |
| Anzahl COM-Anschlüsse | 1 |
| Gleichstrom-Anschluss (DC) | Ja |
Erweiterungssteckplätze
| PCI-Express-Slots-Version | 3.0 |
| PCI-Slots | 1 |
| Anzahl der M.2 (M)-Steckplätze | 1 |
| PCI Express Konfigurationen | 1x4, 2x2, 1x2+2x1, 4x1 |
Design
| Produktfarbe | Schwarz |
| Kabelsperre-Slot | Ja |
| Slot-Typ Kabelsperre | Kensington |
| VESA-Halterung | Ja |
| Panel-Montage-Schnittstelle | 75 x 75,100 x 100 mm |
| Produkttyp | Mini-PC Barebone |
Leistungen
| Prozessorsockel | BGA 1528 |
| Audio-Chip | Realtek ALC255 |
Prozessor Besonderheiten
| Eingebettete Optionen verfügbar | Nein |
| Intel® AES New Instructions (Intel® AES-NI) | Ja |
| Intel® Quick-Sync-Video-Technik | Ja |
| Intel® Clear Video HD Technology für (Intel® CVT HD) | Ja |
| Intel® Turbo-Boost-Technologie | 2.0 |
| Intel® Hyper-Threading-Technik (Intel® HT Technology) | Ja |
| Intel® Virtualisierungstechnik für direkte I/O (VT-d) | Ja |
| Intel® VT-x mit Extended Page Tables (EPT) | Ja |
| Intel® 64 | Ja |
| Intel® My-WiFi-Technik (Intel® MWT) | Ja |
| Leerlauf Zustände | Ja |
| Verbesserte Intel SpeedStep Technologie | Ja |
| Thermal-Überwachungstechnologien | Ja |
| Intel® Flex Memory Access | Ja |
| Intel® Identity-Protection-Technologie (Intel® IPT) | Ja |
| Intel® Trusted-Execution-Technik | Nein |
| Execute Disable Bit | Ja |
| Intel® TSX-NI | Nein |
| Intel® Sicherer Schlüssel | Ja |
| Intel Stable Image Platform Program (SIPP) | Nein |
| Intel® OS Guard | Ja |
| Intel® Clear Video Technologie | Ja |
| Intel® Virtualization Technologie (VT-X) | Ja |
Software
| Unterstützt Windows-Betriebssysteme | Windows 10 |
| Installiertes Betriebssystem | Nein |
Energie
| Stromversorgung | 90 W |
| Netzteil Ausgangsspannung | 19 V |
| AC-Adapter Ausgangssstrom | 4,3 A |
Betriebsbedingungen
| Betriebstemperatur | 0 - 50 °C |
| Temperaturbereich bei Lagerung | -20 - 60 °C |
Gewicht und Abmessungen
| Breite | 119,5 mm |
| Tiefe | 119,5 mm |
| Höhe | 46,8 mm |
Sonstige Funktionen
| ARK Prozessorerkennung | 196451 |
Specs: Icecat.biz
